AQMSPLUS Air Quality Monitoring System Software
The AQMSPLUS Software is a data acquisition software used for the work control of all analyzers and calibration instruments,
data acquisition,remote calibration operation,data communication and other tasks in the monitoring station.
Product Overview
The AQMSPLUS Software is a data acquisition software used for the work control of all analyzers and calibration instruments,data acquisition,remote calibration operation,data communication and other tasks in the monitoring station.
AQMSPLUS Air Quality Monitoring System Software Technical Specifications
Main Technical Parameters
1.The DAS continuously acquires measurement results and status data from all analyzers via RS232/485, wired networks, or wireless networks using a PC.
2.Supports more than 8 digital input ports (16–32 channels or customized on request).
3.System configuration is retained after power failure; upon power restoration, the system automatically restarts and resumes operation.
4.System stability: the software runs on the Windows operating system, ensuring stable and secure performance.
5.System security: encrypted data transmission with strict access control and user authentication protects against internal and external threats.
DAS Functions
1.Alarm management: supports flexible alarm settings and remote display of on-site operating status, instrument alarms, and equipment faults.
2.Equipment control:supports local or remote zero and span calibration and other operational controls.
3.Data storage:stores real-time data and hourly averages for more than one year.
4.User management: provides strict user and permission management.
5.Data query and visualization: enables querying historical data over selected periods, including 5-minute and hourly averages, with graphical trend displays.
